This amp is handmade to order at time of order. Lead time is generally 8-12 weeks. You will be contacted directly upon ordering to discuss the timeline.

Specifications

Input Sensitivity

OP Amp - 0.3 V - 8 V

Direct, Bypass - 0.1 - 1.8 V

Gain +15 dB

Op Amp Option, Burr Brown or Audio Wave

Input Impedance 33k Ohms

Rated Continuous Output at14.4V at 0.1% THD (Class A, A/B)

CR-30X. 8 Ohms - 50W X 1 Class A 50W

CR-30X 4 Ohms - 30W X 1 Class A/B 100W

CR-30X. 2 Ohms - 15W X 1 Class A/B 160W

Minimum Speaker Load 2 Ohms

SNR A/W Full Power at 14.4V

Op Amp > 105 dB

Direct > 118 dB

Bandwidth (Frequency Response) at 2 W

9.5 Hz - 120 kHz - (+/-12 dB)

20 Hz - 20 kHz - (+/-0.3 dB)

Optional DC Protection Below 11 Hz

Phase Switch 180 degrees

Direct Input Op Amp Bypass Switch

Idle Current

CR-30X (+/-10 Amps)

Standby Current

CR-30X (+/-0.03 mA)
