Kicker PXA10005 Waterproof 5-Channel Amplifier (48PXA10005)
$779.99
4 payments of $195.00 with
The CXA360.4 Four-Channel Amplifier is built to power all your door speakers in a single, powerful package.
In stock
1
Customer reviews
Reviews only from verified customers
No reviews yet. You can buy this product and be the first to leave a review.
Kicker PXA10005 Waterproof 5-Channel Amplifier (48PXA10005)
Product Details
Brand: Kicker
Amplifier Channels: 5
Kicker PXA1000.5 Waterproof 5-Channel Amplifier with Subwoofer (48PXA10005)
Completely re-engineered, the PXA1000.5 is a single-amp solution to an entire system! It supplies big full-range power, in a compact, waterproof design for the trickiest installs.
PXA1000.5 Amp Features Enhanced Tuning: Tune this PXA Multi-Channel Amp from your PC for an enhanced listening experience! The PXAPT DSP Programming Adapter offers that capability by connecting you to Kicker Powersports Tuneâ„¢ software, allowing you to control EQ and crossovers independently per channel, or combine them with channel linking. Added parametric EQ dials in your system the way you want to hear it. Advanced crossover controls let you pick your topology, slopy, and frequency of choice. Create and save tunes for multiple applications.
Features
- Waterproof amplifier design with IP66 and IP67 certifications
- Ideal for UTVs, off-road vehicles, hot rods or space-challenged vehicles
- High-efficiency Class-D technology
- Huge power from a small footprint – rated at 1400 Watts Dynamic Power!**
- Included subwoofer channel stable at one-Ohm
- Dual turn-on modes (choice of DC offset or 12v trigger)
- Includes inline power and ground couplers that need no soldering or crimping
- Stainless-steel mounting hardware included
If you have two mono amps or powered subwoofers, check out the Kicker DBRC Remote (51DBRC) for controlling both from the same knob.
Specifications
|
Power (Watts/ch*), 2 Ohm Stereo: 150 x 4 |
|
Power (Watts/ch*), 4 Ohm Stereo: 100 x 4 |
|
Power (Watts/ch*), 1 Ohm Mono: 600 x 1 (sub channel) |
|
Power (Watts/ch*), 2 Ohm Mono: 500 x 1 (sub channel) |
|
Power (Watts/ch*), 4 Ohm Bridged Mono / 4 Ohm Mono (Sub): 300 x 2 (amp 1 and 2); 300 x 1 (sub ch) |
|
Dynamic Power (Watts):** 1400 |
|
Frequency Response (Hz, +0/-3dB): (FR) 10 – 20k; (sub) 25 - 200 |
|
Crossovers: 24 dB/octave highpass 80/120Hz (amp 1 and 2); lowpass 6080100120 Hx (sub only); subsonic 25 Hz, 24 dB/octave (sub only) |
|
Bass Boost: selectable 0/+6 dB, centered at 40 Hz (sub channel only) |
|
Dimensions (in, mm): W: 4-1/2, 114.7; H: 1-15/16, 50; L: 12-7/8, 327.5 |
|
CXARC Remote capable (sold separately): Yes (sub channel only) |
|
What's in the Box: |
|
Waterproof IP66/IP67 power sports amplifier
|
|
Warranty |
|
Kicker warrants this product to be free from defects in material and workmanship under normal use for a period of two (2) years from date of original purchase. |
*RMS Power test at 14.4 v at <1% THD+N, Audio Precision™ analyzer, see Kicker Amplifier Power Testing document here for details. See full discussion of Kicker’s amp testing procedures here.
**Dynamic Power test at 14.4 v at <10% THD+N, Audio Precision™ APx500 analyzer, see Kicker Amplifier Power Testing document here for details. See full discussion of Kicker’s amp testing procedures here.
Audio Precisionâ„¢ is a registered trademark of Audio Precision in the United States and other countries.
RMS = Root Mean Square, measure of continuous power in audio devices
THD+N = Total Harmonic Distortion (THD, amount of unwanted frequencies, i.e., distortion) plus Noise (N, all sounds coming from the device other than the input signal). THD+N assesses device sound fidelity.
Due to continual development, product and specifications are subject to change without notice. Stillwater Designs and its agents are not responsible for typographical errors.
Manufacturer's Documents
MANUAL for Kicker PXA Amplifiers
WHITE PAPER for Kicker PXA1000.5 Amplifier
