Mosconi PRO 5-30 5-channel amplifier with Class D mono output, Class AB, asymmetrical power output

The Mosconi PRO 5|30 already signals the high-end claim with its design: With rounded aluminum edges and contrasting black perforated sheet insert with illuminated logo, the amplifier looks very noble. The eye finds numerous steps and recesses on which the gaze lingers without the whole looking jagged.

The Mosconi Pro 5|30 is a hybrid amplifier in a class of its own. It achieves extensive system configurations. With its asymmetrical power distribution, when used in conjunction with a digital sound processor, it perfectly creates active operation. Additional features include:

• Direct DSP (bypassing all preamplifier circuits)
• High level / low level selectable input
• Autosense (only in BTL mode)
• RTC - Allows volume regulation by remote control (optional)
• Power supply and temperature management controlled by microprocessor

Optional: RTC-2 for remote control operation.

Features

• 5 channel amplifier
• Class AB technology with Class D mono output
• Asymmetrical power output

Manufacturer Specifications

Output Power:

Output power at 4 Ohms: 2 x 95 + 2 x 185 + 1 x 660 Watts

Output power at 2 Ohms: 2 x 150 + 2 x 290 + 1 x 1030 Watts

Specifications:

Input sensitivity:

• 0.35 V ÷ 12 V (5.3 V in DDSP mode) [CH 1/2/3/4]
• 0.14 V ÷ 5.9 V (3.1 V in DDSP mode) [CH 5]

Crossover:

• CH 1/2 = HP: 43 ÷ 500 Hz (x 1) or 430 ÷ 5000 Hz (x 10)
• CH 3/4 = HP: 50 ÷ 200 Hz & LP: 430 ÷ 5000 Hz
• CH 5 = LP: 43 ÷ 200 Hz

Signal to Noise Ratio: > 83 dBA (ref: 1 Watt into 4 Ohms)
Dimensions: 500 x 205 x 55 mm

Weight: 5.4 kg (5,400 grams)

(RMS = Root Mean Square, measure of continuous power in audio devices)

Manufacturer Documents

DATA SHEET for Mosconi PRO 5-30 Amp

MANUAL for Mosconi PRO 5-30 Amp
